Mainboard GIGABYTE X299 AORUS MASTER - Socket LGA 2066

Detail Mainboard GIGABYTE X299 AORUS MASTER - Socket LGA 2066

Intel X299 AORUS Motherboard with 12 Phases Digital VRM, Fins-Array Heatsink with 6mm heatpipe, 2.5GbE LAN and Intel LAN, 802.11ac Wireless with High Gain Antenna, Triple M.2 with Thermal Guards, ESS SABRE 9218 DAC, Front & Rear USB 3.1 Gen 2 Type-C

Supports 9th Gen Intel Core X Series Processors
Quad Channel Non-ECC Unbuffered DDR4, 8 DIMMs
Intel Optane Memory Ready
12 Phases Digital VRM Solution with Smart Power Stage
Advanced Thermal Design with Fins-Array and 6mm Heatpipe
Realtek 2.5GbE onboard and Intel Gigabit LAN with cFosSpeed
Onboard Intel 802.11ac 2x2 Wi-Fi & AORUS Antenna
130dB SNR AMP-UP Audio with High-End ESS SABRE 9218 DAC, ALC1220 and WIMA audio capacitors
USB TurboCharger for mobile device faster charging support
RGB FUSION 2.0 with Multi-Zone RGB LED Light Show design, support Addressable LED & RGB LED strips
Smart Fan 5 features Multiple Temperature Sensors and Hybrid Fan Headers with FAN STOP
Front USB 3.1 Gen 2 Type-C Header
Triple Ultra-Fast M.2 with PCIe Gen3 x4 interface with Triple Thermal Guards
USB DAC-UP 2 with Adjustable Voltage

CPU
Support for Intel Core X series 44-lane/28-lane processors (6-core or above) in the LGA2066 package
L3 cache varies with CPU
(Please refer "CPU Support List" for more information.)
Chipset
Intel X299 Express Chipset
Memory
8 x DDR4 DIMM sockets supporting up to 128 GB of system memory
4 channel memory architecture
Support for DDR4 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666(O.C.) / 2400 / 2133 MHz memory modules
Support for non-ECC Un-buffered DIMM
Support for Extreme Memory Profile (XMP) memory modules
