Mainboard Gigabyte A320M-S2H - AM4 - Mainboard AMD A320M 2SH - AMD AM4 Gigabyte A320MS2H

Detail Mainboard Gigabyte A320M-S2H - AM4 - Mainboard AMD A320M 2SH - AMD AM4 Gigabyte A320MS2H

-Supports AMD Ryzen™ & 7th Generation A-series/ Athlon™ Processors
-Dual Channel Non-ECC Unbuffered DDR4, 2 DIMMs
-Ultra-Fast PCIe Gen3 x4 M.2 with PCIe NVMe & SATA mode support
-High Quality Audio Capacitors and Audio Noise Guard
-Realtek® Gigabit LAN with cFosSpeed Internet Accelerator Software
-Smart Fan 5 features 5 Temperature Sensors and 2 Hybrid Fan Headers
-GIGABYTE™ UEFI BIOS
-All New GIGABYTE™™ APP Center, Simple and Easy Use


CPU
AM4 Socket:
AMD Ryzen™ processor
AMD 7th Generation A-series/ Athlon™ processor
(Please refer "CPU Support List" for more information.)

Chipset
AMD A320

Memory
2 x DDR4 DIMM sockets supporting up to 32 GB of system memory
Dual channel memory architecture
Support for DDR4 3200(O.C.)/2933(O.C.)/2667*/2400/2133 MHz memory modules
* Actual support may vary by CPU.
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules
(Please refer "Memory Support List" for more information.)

Onboard Graphics
Integrated Graphics Processor:
1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
* The DVI-D port does not support D-Sub connection by adapter.
1 x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz
* Support for HDMI 1.4 version.
Maximum shared memory of 2 GB
* Actual support may vary by CPU.

Audio
Realtek® ALC887 codec
High Definition Audio
2/4/5.1/7.1-channel
* To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.
Support for S/PDIF Out

LAN
Realtek® GbE LAN chip (10/100/1000 Mbit)
