Mainboard Asus Maximus VIII Extreme - LGA1151 Intel Z170 Intel Gen 6/7

Detail Mainboard Asus Maximus VIII Extreme - LGA1151 Intel Z170 Intel Gen 6/7

CPU
Intel Socket 1151 for 6th Generation Core i7/Core i5/Core i3/Pentium/Celeron Processors
Supports Intel 14 nm CPU
Supports Intel Turbo Boost Technology 2.0
* The Intel Turbo Boost Technology 2.0 support depends on the CPU types.
* Refer to for CPU support list

Chipset
Intel Z170

Memory
4 x DIMM, Max. 64GB, DDR4 3866(O.C.)/3800(O.C.)/3733(O.C.)/3600(O.C.)/3500(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666(O.C.)/2400(O.C.)/2133 MHz Non-ECC, Un-buffered Memory
Dual Channel Memory Architecture
Supports Intel Extreme Memory Profile (XMP)
* Hyper DIMM support is subject to the physical characteristics of individual CPUs.
* Refer to for the Memory QVL (Qualified Vendors Lists).

Graphic
Integrated Graphics Processor- Intel HD Graphics support
Multi-VGA output support : HDMI/DisplayPort 1.2 ports
- Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz
- Supports DisplayPort with max. resolution 4096 x 2304 @ 60 Hz
Maximum shared memory of 512 MB
Supports Intel InTru 3D, Quick Sync Video, Clear Video HD Technology, Insider

Multi-GPU Support
Supports NVIDIA Quad-GPU SLI Technology
Supports AMD 4-Way CrossFireX Technology

Expansion Slots
3 x PCIe 3.0/2.0 x16 (x16 or dual x8 or x8/x4/x4, gray)
1 x PCIe 3.0/2.0 x16 (x4 mode, gray)
2 x PCIe 3.0/2.0 x1 (black)

Storage
Intel Z170 chipset :
1 x M.2 x4 Socket 3, with M Key, type 2242/2260/2280/22110 storage devices support (both SATA & PCIE mode)*1
6 x SATA 6Gb/s port(s), gray, , 4 ports from 2 x SATA Express
2 x SATA Express port
1 x U.2 port
Support Raid 0, 1, 5, 10
Intel Rapid Storage Technology supports*2
Supports Intel Smart Response Technology*2
ASMedia ASM1061 controller :
2 x SATA 6Gb/s port(s), black, *3,
