{LUCKID}433Mhz 1CH RF relay receiver wireless remote control light switch micro module

Perlengkapan Rumah > Perkakas > Perkakas Lainnya > {LUCKID}433Mhz 1CH RF relay receiver wireless remote control light switch micro module
  • Pengiriman Ekspres
  • Barang yang diperiksa
  • Bayar di tempat berlaku
  • Kualitas, Prestise
  • Pengembalian produk
  • Dukung pembuatan faktur

Detail {LUCKID}433Mhz 1CH RF relay receiver wireless remote control light switch micro module

Features:
Wireless control LED lamp string, Christmas tree light string, light control switch
Long range working voltage
Ultra low power,High sensitive response
Specification:
Working voltage: DC 3.6V~24V
Maximum load: 2A
Static current: 3.6 mA ~ 5.5mA
Working frequency: 433MHz
Reception sensitivity: ≥ -107dBm
Output DC3.6V~DC24V
Size: 22.5 mm x 11mm x 8mm (length × width × high)
Mini size support coding format 1527 learning code
Input: DC3.6V~DC24V
Output: DC3.6V~DC24V
Modulation mode:ASK (superheterodyne)
Appearance size: 22.5mmx 11mm x 8mm (length × width × high)
Number of stored remote controls: ≤ 10
Working mode: Momentary, Toggle, Latching Mode
Learning style: Learning Button
Working temperature: -20 degrees 80 degrees
Package Include:
1 pcs * Light Switch Receiver Module
