Detail LRD14 Relay Schneider TeSys LRD Thermal Overload Relay Original

Deskripsi LRD14 Relay Schneider TeSys LRD Thermal Overload Relay Original

LRD14 Relay Schneider TeSys LRD Thermal Overload Relay Original

Product Attribute : Attribute Value
Control Voltage : 690 VAC
Current Rating : 7-10 A
Depth : 2.756" (70mm)
Family Name : TeSys Family
Function : Overload
Length : 1.772" (45mm)
Maximum Operating Temperature : 60°C
Minimum Operating Temperature : -20°C
Mounting Style : DIN Rail, Plate
Primary Type : Contactor
Relay Type : Electromechanical
Series : TeSys LRD Series
Size : 70 L x 45 W mm
Supply Voltage : 690 VAC
Temperature Operating Range : -20 to 60°C
Terminal Type : Screw Clamp
Type : Relay
UPC Code : 785901206774

chneider Electric TeSys LRD Series — Thermal Overload Relays for TeSys D Contactors Class 10 A | Class 20:

The TeSys LRD features an integrated manual-automatic reset button and simple installation using screw clamp terminals, spring terminal, ring terminals, or EverLink terminals. TeSys LRD thermal overload relays are very reliable and cover a wide range of motor ratings up to 150 A.

Features:

- Manual and automatic reset
- Sealable flap
- Pre-wiring kit
- Terminal block for separate mounting
- Remote electrical reset
- Can be combined with TeSys D contactors in a 45 mm wide space up to 38A , 55 mm from 40A to 65A
- Connectors: spring terminal, screw clamp, EverLink terminal block
- Class 10 & Class 20

Ukuran kemasan : 9x9x6 cm
Berat : 210 gram
