Detail Load Cell ZEMIC H3 C3 500kg Tipe S Loadcell Sensor Berat Timbangan Digital
Spesifikasi : Model: H3-C3-500kg-3B Kapasitas : 500kg Class : C3 Material: ALLOY STEEL Full Scale Output: 2.0023 mV/V Non-Repeatability: ±0.01% of FS Input Resistance: 350±3.50 Temp,Sens,Zero: ±0.015% FS/10°C Temp, Sens, Output:±0.011% FS/10°C Non-linearity: ±0.02% of FS Cabie Lengty: 3m Safe Overload(150%): 750kg Ultimate Overload (300%): 1500kg Excitation: 5-12VDC(NOM). 18VDC(MAX) Insul Res: > 5000MQ(50VDC) Combined Error: ±0.02% of FS Zero Balance: ±1.0% of FS Output Resistance: 351+±20 Comp,Temp.Range: -10°C -40°C Operating Temp: -35°C-70°C Hysteresis:±0.02% of FS
Note : Wajib melakukan video unboxing saat membuka paket mulai dari awal hingga akhir. Kami tidak menerima complain apapun jika tidak ada video unboxing.
