Lithium Battery Charger 4s 30A Module

Detail Lithium Battery Charger 4s 30A Module

Lithium Battery Charger 4s 30A Module
Modul charger utk baterai lithium dengan proteksi over charge , over discharge, dan korslet

Deskripsi Produk:
++ Module: 4S Li-ion Lithium Battery Protection Board
++ over charge detection voltage :4.25+/-0.025V
++ over charge Lift the voltage:4.15+/-0.05V
++ over discharge detection voltage :2.50+/-0.08V
++ over discharge Lift the voltage:3.00+/-0.1V
++ over current current:20-30A
++ working current: 15A(Natural cooling 10.A, add heat sink 15A, the maximum instantaneous current 30A)
++ Remove protection condition automatic recovery, without activation
++ Protections: Short circuit protection
++ Overcharge protection
++ Over-discharge protection
++ Overcurrent protection
++ Operating temperature:40-85 Degrees Celsius
++ Size:50 x 22 x 4mm / 1.97 x 0.87 x 0.16 inch
++ Material:Plastic
++ Colour:Red

Isi Paket :
1x Lithium Battery Charger 4s 30A Module
