airMAX LiteBeam AC 5 GHz CPE
Ultra-lightweight, outdoor, wireless CPE designed to create extremely long-distance links.
The airMAX®️ LiteBeam®️ AC 5 GHz CPE (LBE-5AC-XR) is designed to sustain high-speed connections over very
long distances, allowing you to serve more subscribers with just a single device. The LBE-5AC-XR also features a
proprietary, high-gain antenna capable of delivering 450+ Mbps throughput over the 5 GHz frequency range.

Mechanical
Dimensions: 747 x 525 x 347 mm (29.41 x 20.67 x 13.66")
Weight : 3.2 kg (7.06 lb)
Enclosure materials: Aluminum alloy, UV stabilized polycarbonate
Mount material : UV stabilized polycarbonate
Mount : Integrated pole mount (included)
Pole compatibility: Ø35-60 mm (Ø1.38-2.36")
Wind loading : 1100 N at 200 km/h (247.29 lbf at 125 mph)
Weatherproofing : IPX6

Hardware
Networking interfaces : (1) GbE RJ45 port
Button : Factory reset
LEDs : Power/ethernet
RF connections : Internal
Max. power consumption : 7W
Power method : Passive PoE 2-pair (4, 5+; 7, 8-)
Power supply : 24VDC, 0.5A Gigabit PoE adapter (included)
Supported voltage range : 22-26VDC
Operating temperature : -40 to 70° C (-40 to 158° F)
Operating humidity : 5 to 95% non-condensing
Certification : FCC, IC, CE

System
Maximum throughput : 450+ Mbps
Encryption : WPA2-PSK (AES)

Software
OS : airOS®️
Modes : PtMP, PtP
Services : SNMP, SSH, dynamic DNS, webserver, remote log, ping watchdog
Utilities : airView®️, speed test, alignment, discovery, ping, traceroute, constellation
Management interface : Dedicated management radio for quick device setup via the UISP™️ Mobile app WEB UI
Minimum software requirements : Modern Web browser or Android/iOS smartphone

RF
Operating frequency* : 5.15 to 5.85 GHz * Depends on regulatory region.
Max. conducted TX power : 25 dBm
Management radio : 2400 - 2483.5 MHz
Channel bandwidth : 10/20/30/40/50/60/80 MHz
Antenna Gain : 29 dBi
Isolation : 20 dB
Beamwidth : HPOL: 3 dB: 5.5°, 6 dB: 7.5°
VPOL: 3 dB: 5.5°, 6 dB: 7.5°
Elevation: 3 dB: 5.5°, 6 dB: 7.5°
Electrical downtilt : 0°
