Linksys LGS308MP PoE+ Smart 8 Port Gigabit Network Switch 130W
Merek: Linksys | Lihat selengkapnya produk Komputer & Aksesoris dari LinksysDeskripsi singkat
Komputer & Aksesoris > Komponen Network > Switch Internet & PoE > Linksys LGS308MP PoE+ Smart 8 Port Gigabit Network Switch 130W
- Pengiriman Ekspres
- Barang yang diperiksa
- Bayar di tempat berlaku
- Kualitas, Prestise
- Pengembalian produk
- Dukung pembuatan faktur
Produk Terkait
Detail Linksys LGS308MP PoE+ Smart 8 Port Gigabit Network Switch 130W
Model Name:LGS308MP
Ports:
Total System Ports: 8GE
Copper FE/GE Ports (RJ45): g1–g8
Memory:
128 MB
LEDs:
System (blue), Link/Act/PoE (green/green)
System Power Consumption without PoE+:
110V:10.82W
220V:10.59W
Forwarding Rate:
11.90 Mpps
Switching Capacity:
16 Gbps
MAC Address Table Size:
8K
Jumbo Frame (FE, GE):
9K
Dimensions (LxWxH):
210 x 104 x 25 mm
(8.3 x 4.1 x 1.0 in.)
Weight:
0.58kg (1.28 lbs)
Power Dedicated to PoE+:
130W
Power Input:
100–240V
50–60 Hz
(3.34A max)
Power Saving:
EEE+, Short Reach + Energy Detect
Operating Temperature:
0 to 50°C (32 to 122°F)
Storage Temperature:
-40 to 70°C (-40 to 158°F)
Operating Humidity:
10 to 90% RH
Storage Humidity:
10 to 90% RH (non-condensing)
Spanning Tree:
IEEE 802.1d Spanning Tree, IEEE 802.1w Rapid Spanning Tree, IEEE 802.1s Multiple Spanning Trees
Link Aggregation:
IEEE 802.3ad LACP, up to 4 groups with up to 8 ports per group
VLAN:
Port-based and 802.1q tag-based VLANs, Management VLAN, Guest VLAN support, Dynamic VLAN assignment via Radius server with 802.1x client authentication
Number of VLANs Supported:
128 active VLANs (4,096 range)
Auto Voice VLAN:
Voice traffic is automatically assigned by OUI to a voice-specific VLAN and treated with appropriate levels
IGMP Snooping:
IGMP (v1/v2/v3) snooping provides for fast client joins and leaves of multicast streams and limits bandwidth-intensive video traffic to only the requestors; supports 256 multicast groups
HOL Blocking Prevention:
Head of line (HOL) blocking prevention
Port Mirroring:
Traffic on multiple ports (up to 4 ports) can be mirrored to another port for analysis with a network analyzer
Security Features:
802.1x Radius authentication
DHCP snooping
IP-MAC binding
Port security supports limited dynamic lock and locked MAC address
Management access control
Storm Control:
Broadcast, flooding, and multicast
Quality Of Service:
Port-based, 802.1p priority-based, IPv4/v6 IP DSCP-based
Gambar produk
