Detail LED Backlight TV 2W 3535 6V Cool white New Seoul LG innotek

Deskripsi LED Backlight TV 2W 3535 6V Cool white New Seoul LG innotek
Deskripsi 3535 smd led cold white, 6v 2w New Seoul pengganti LG INNOTEK
Harap dibaca sebelum membeli
Harga per 1 biji

Spesifikasi:
Forward Current (IF ): 500mA
Pulse Forward Curren t1 (IFp): 800mA
Reverse Current (IR): 50mA
Reverse Voltage (VR): V (mA)
Power Dissipation (PD): 2W
Operatin Tgemperature (Topr): -40 - +85C
Storage Temperature (Tstg): -40 - +100C
Soldering Temperature (Tsld): Reflow Soldering:260C for10secs
Hand Soldering:350C for3secs
Junctio Tnemperature (Tj):162C
Forward Voltage (VF): 6.0-6.8V (250mA)
Luminous Flux (LM): 150lm (250mA)
Viewing angle : 120
Lead Frame Type LED Package: 3.53.50.65 mm LWH d=mm
