LED BACKLIGHT LV LCD 7032 3V SAMSUNG SMD

Elektronik > Baterai > LED BACKLIGHT LV LCD 7032 3V SAMSUNG SMD
Tersedia
Periksa harganya...
Lihat tempat menjual
Toko:LED PekanbaruLihat semua produk Elektronik oleh LED Pekanbaru
  • Pengiriman Ekspres
  • Barang yang diperiksa
  • Bayar di tempat berlaku
  • Kualitas, Prestise
  • Pengembalian produk
  • Dukung pembuatan faktur
DeskripsiSpesifikasi

Detail LED BACKLIGHT LV LCD 7032 3V SAMSUNG SMD

MODEL NAME : SPBWH1732S1B 7032 LED
Forward Current (IF ):120mA
Pulse Forward Curren t1 (IFp):200mA
Reverse Current (IR):uA
Reverse Voltage (VR):0.7-1.2V (5mA)
Power Dissipation (PD): W
Operatin Tgemperature (Topr): - 40 +85C °
Storage Temperature (Tstg): -40 - +100 C °
Soldering Temperature (Tsld): Reflow Soldering:260 C ° for 10secs
Hand Soldering:350C ° for 3secs
Junctio Tnemperature (Tj ): C °
Forward Voltage (VF): 2.95 - 3.4V (120mA)
Luminous Flux (CD): 9.86 - 13.84CD (120mA)
Wavelength (nm) : 438.1 -455.9 nm (120 mA)
Color coordinates (CIE) : X:0.2438 Y:0.2059
Color Correlated Temperature (CCT): K
CRI : °
Viewing angle : 120°

Gambar produk
