Detail LA78141 LA 78141

LA 78141 ORIGINAL STOK TERBATAS. BARANG SAMA DENGAN FOTO


Description

The LA78141 is a vertical deflection output IC for high image quality TV andCRT displaysthat supports the use of a bus control systemsignal-processingIC.

The sawtooth waveform from the bus control system signal-processing IC can directly drive the deflection yoke (including the DC component). Color TV vertical deflection system adjustment functions can be controlled over a bus system by connecting the LA78141N to a Sanyo LA768X series or LA769XX series bus control system signal-processing IC


LA78141 Pinout

1.Invertin Input
2.VCC
3.Pump Up Out
4.Gnd
5.
6.Output Stage VCC
7.Non Multimedia Misc Vertical Output IC

Gambar produk
