KWH Meter 3 Phase

Detail KWH Meter 3 Phase

Tipe : TEM021N-D85G3 Rating Direct Conn. 3 x 5(100)A

FUNCTIONS:
TEM021N-D Series adalah LCD 7-Module DIN-Rail kWh/Energy meter elektronik tiga fase untuk
mengukur besarnya pemakaian listrik/energi kWh pd jaringan 3-Phase.

FEATURES:

Wide rage current measurement
Programmable CT ratio
Rs485 & InfraRED port
Test/SO pulse output port
DIN-Rail Mounting & Size 7-DIN modules
Easy Installation
SPECIFICATIONS:

Measuring : kwh (mengukur Konsumsi Listrik/Energi jaringan 3-Phase)
Connecting Mode: Direct
Accuracy Class: Class 1.0
Display: 6(5+1) digits LCD Display

Reference Voltage (Un): 3 X 230/400V AC (3~)

Operating Voltage: 3-Phase/4-Wire, 161/279-300/520V AC (3~)

AC Voltage withstand: 2 KV for 1 minute

Impulse Voltage: 6kV-1.2/50S waveform

Rate Current (Ib) / (Imax) : 1.5(5)A Via CT and 5(100)A Direct

Operating Current Range: 0.2%Ib ~ Imax Via CT or 0.5%Ib ~ Imax for Direct

Operating Frequency: 50 Hz +/- 10%

Internal Power Consumption: <2W/10VA /Phase

Index Protection of Dust/Water: IP51 Class II

Authority International Standard IEC 62053-21 dan DIN EN50022

Sudah termasuk Sertifikat test Tera Indonesia

COMMUNICATIONS PORT:

Pulse Output (Open Collector): 3600 imp/kWh for CT & 10 kWh/imp for Directable to connect to THERA TMEX16DI Pulse Concentrator Module.
RS485 & InfraRED Port with Protocol DL-645/2007 able to connectto THERA PCREAD METER Software
