Konverter Serial RS232/RS422/RS485 to Ethernet Adapter CHRONOS

Detail Konverter Serial RS232/RS422/RS485 to Ethernet Adapter CHRONOS

USR-TCP232-304 is a low-cost serial RS485 Ethernet converter, which can realize bidirectional transparent transmission between RS485 and local Ethernet or Internet. It is integrated with TCP/IP protocol.

Features of RS485 Ethernet Converter :
1. Support DHCP, automatically obtain an IP address and query IP address through serial setting protocol
2. Support DNS function
3. Set parameters through webpage
4. Upgrade firmware via network
5. Auto-MDI/MDIX, RJ45 port with 10/100Mbps
6. Serial port baud rate from 600 bps to 230.4 Kbps, Check bit of None, Odd, Even, Mark and Space
7. Work mode: TCP Server, TCP Client, UDP Client, UDP Server, HTTPD Client
8. Support virtual serial port and provide corresponding software USR-VCOM
9. Heartbeat package mechanism to ensure connection is reliable, put an end to dead link
10. User-defined registration package mechanism, check connection status and use as custom packet header
11. Under TCP Server mode, Client number ranges from 1 to 16; default number is 4
12. The global unique MAC address bought from IEEE, user can define MAC address
13. Restore factory default
14. Across the gateway, switches, routers
15. Can work in LAN, also can work in the Internet (external network)
16. Provide PC TCP/IP socket programming example such as VB,C++,Delphi,Android and IOS

Application Field of RS485 Ethernet Converter
1. Industrial data transmission, industrial automation
2. security and protection monitoring, public security
3. Smart home, power control, environmental monitoring, intelligent agriculture
4. Door check on work attendance system, POS system, rice selling system
5. Building automation system, power monitoring, self-service banking system, telecom machine room monitoring

Packing List :
1. RS485 to Ethernet converter *1
2. Power adapter *1

Gambar produk
