Kit Modul Mp3 Bluetooth 5.0 Decoder Wireless DC12v Support TF USB U disk FM Radio

Detail Kit Modul Mp3 Bluetooth 5.0 Decoder Wireless DC12v Support TF USB U disk FM Radio

12V DIY Wireless MP3 Decoder Board Bluetooth 5.0 amplifier Support TF USB U disk FM Radio

Sepcification:
1.TF: Connect TF memory card (maximum support 32GB)
  2.USB: Connect U disk (maximum support 32GB)
  3. LED indicator
4.PREV/VOL-: Short press is to select the previous song; long press is to decrease the volume
5.PLAY/PAUSE: Short press is the switch between pause and play; long press is the switch of USB / TF / FM / AUX / BLUETOOTH; in the FM FM state, the pause play button is automatic search;
6.NEXT/VOL+: Short press is to select the next song; long press is to increase the volume;

Description
Main control IC: AC6925A
Bluetooth IC: AC6925A
Bluetooth version: V5.0
Music format: MP3 / WMA / WAV / FLAC / APE lossless format
Radio FM frequency: 87.5-107.5 MHZ
Function introduction: support MP3/USB/TF/LINE IN/FM/BLUETOOTH/DC
Panel size: 50 * 24 MM, the depth of the board is 35MM
