Detail Kabel STP/FTP Cat5e Zimmlink STP Cat5e Outdoor CCA OD Zimm LINK Double Jacket
Kabel FTP CAT5e Outdoor ZimmLink CCA OD double jacketNB :
Mohon Chat dulu sebelum ORDER
untuk update stok nya
Spesifikasi FTP CAT5e Outdoor Used Cable Zimmlink
Conductor
Material : CCA
Size :24AWG*4P
Insulation
Material : PE
AVG.Thicknes :0.20MM
Min Thickness :0.18MM
Inner Layer
Direction : S
Pitch : 30mm Underneath
Outside Layer
Direction : S
Pitch : 200mm Underneath
Separate
Material :
Shielding
Material :mylar Spirally Wrapped
Coverage :100% coverage with 25% overlapping
drain wire :1/0 35CCA
Material : Alumunium mylar Spirally Wrapped 100% covverage with 25% overlapping face inside
Filler
Material :nylon
Jacket
MAterial :PE
AVG.Thickness :0.55MM
Min.Thickness :0.48MM
Diameter : Optional
Marking : Meter
Packing : Cartoon
Electrical Properties
Insulaltion Ressistance
Dielectric Test : 1000V DC/:min No breakdwon
Voltage Rating : 30V
