Kabel LAN RJ45 Cat 6 STP Outdoor 305 Meter ORIGINAL BELDEN

Detail Kabel LAN RJ45 Cat 6 STP Outdoor 305 Meter ORIGINAL BELDEN

BELDEN 50106F 010 BLK Industrial Cable STP Cat. 6 Outdoor Shielded
BELDEN 50106F 000 GRY Industrial Cable STP Cat. 6 Outdoor Shielded

Industrial Ethernet cables used in interconnecting Industrial Ethernet Switches, IP controllers, media convertors, distributed control system, programmable logic controller and transmitting industrial protocol data signals. These cables are suitable for transmitting 1000BASE‐TX Gigabit Ethernet, 100BASE‐T Fast Ethernet, 100BaseVG ANYLAN, 155ATM, 622ATM, RS‐422, 250MHz Category 6, EtherCAT. These are highly durable & ruggedized cables for both indoor and outdoor use meeting IEC 60332‐3‐25 Category D flame rating.

General Reference Standards
11801 Category 6, TIA/EIA 568C.2 Cat 6
IEC 60332‐3‐25, UL 1685, UL 1581, ICEA S 73‐532, IEC 60332‐1
EU RoHS

Physical Characteristics
Conductor Size 23 AWG
Conductor Material Solid Bare Copper
Insulation Material PO ‐ Polyolefin
Number of Pairs 4 Pairs
Shielding Aluminium Foil – Polyester Tape with TC drain wire
Jacket Material PVC ‐Polyvinylchloride
Suitability Indoor and Outdoor
UV/Sun Light Resistance Yes
Oil Resistance Yes
Flame Retardant IEC 60332‐3‐25 Category D UL 1685 UL Loading
UL Specification CM
Other Specifications ISO/IEC 11801 Class E TIA/EIA 568‐C.2 Category 6
Nom. Diameter 7.5 mm

Electrical Characteristics
Max. Conductor DCR @ 20°C 9.38 Ω/100m
Characteristic Impedance 100 ± 15 Ω
Nom. Mutual Capacitance @1KHz 5.6 nF/100m
Max. Capacitance Unbalance 330 pF/100m
Nom. Velocity of Propagation 70%
Max. Intended Operating Voltage Rating ‐ UL 300 V
Max. Delay @ 100MHz 538 ns/100m
Max. Delay Skew 45 ns/100m
DCR Unbalance @ 20°C Max. 5%

Mechanical Characteristics
Operating Temperature Range ‐20°C To +75°C
Bulk Cable Weight 62 kg/km
Max. Recommended Pulling Tension 110 N
Min. Bending Radius (Install) 60 mm
