Kabel LAN CAT 6 Dahua DH-PFM922I-6UN-C 1 Roll

Komputer & Aksesoris > Komponen Network > Kabel Network & Konektor > Kabel LAN CAT 6 Dahua DH-PFM922I-6UN-C 1 Roll
  • Pengiriman Ekspres
  • Barang yang diperiksa
  • Bayar di tempat berlaku
  • Kualitas, Prestise
  • Pengembalian produk
  • Dukung pembuatan faktur

Detail Kabel LAN CAT 6 Dahua DH-PFM922I-6UN-C 1 Roll

HARAP MEMASTIKAN STOK TERLEBIH DAHULU SEBELUM MELAKUKAN TRANSAKSI

Untuk pengiriman ke luar kota, Wajib tambahkan packing untuk keamanan pengiriman dengan link berikut ini,
untuk dus :
https://shopee.co.id/PACKING-KARDUS-i.75752086.11869241633?sp_atk=ccda4f9e-a299-446e-adbd-275a77480277
Buble wrap :
https://shopee.co.id/PACKING-BUBBLE-WARP-BUNGKUS-BARANG-ANTI-SHOCK-i.75752086.13345605923?sp_atk=8ddf707c-bf89-41ab-93ab-fe05fadd109a

Conductor
Material : CCA(Copper content 22%–31%)
Diameter : 0.57 mm ± 0.01 mm
American : Wire Gauge 23AWG
Insulation
Material : HDPE
Min. Average Thickness 0.21 mm
Diameter 1.02 mm ± 0.06 mm
Color (4 Pairs) Blue, white/blue; orange, white/orange; green, white/green; brown, white/brown
Separator
Material PE
Specification Translucent 4.5 × 0.4 mm
Rip Cord
Material Polyester
Specification 500D
Sheath
Material PVC
Min. Average Thickness 0.5 mm
Diameter 6.5 mm ± 0.3 mm
Electrical
Max. DC Resistance of a Single Conductor 11.5Ω/100 m
Min. Insulation Resistance 5000MΩ•km
Max. DC Resistance Unbalance 2% (pair intra), 4% (pairs inter)
Dielectric Strength No breakdown with 1KV DC for 1 min
Transmission
Characteristic Impedance 100 ± 15Ω
Near End Cross Talk ≥39.30 dB/100 m@250 MHz
Max. Attenuation 34.8 dB/100 m@250 MHz
Return Loss ≥17.3 dB/100 m@250 MHz
Mechanical
Tensile Strength Sheath≥13.5 MPa, insulation≥16 MPa
Elongation at Break Sheath≥150%, insulation≥300%
