KABEL CCTV COAXIAL 77% COLAN RG6 PLUS POWER DC 100 METER

Merek: Colan | Lihat selengkapnya produk Komputer & Aksesoris dari Colan
Komputer & Aksesoris > Komponen Network > Kabel Network & Konektor > KABEL CCTV COAXIAL 77% COLAN RG6 PLUS POWER DC 100 METER
Tersedia
Periksa harganya...
Lihat tempat menjual
Toko:Sivali Indo NetworkLihat semua produk Komputer & Aksesoris oleh Sivali Indo Network
  • Pengiriman Ekspres
  • Barang yang diperiksa
  • Bayar di tempat berlaku
  • Kualitas, Prestise
  • Pengembalian produk
  • Dukung pembuatan faktur
DeskripsiSpesifikasi

Detail KABEL CCTV COAXIAL 77% COLAN RG6 PLUS POWER DC 100 METER

Kabel CCTV Coaxial 77% COLAN RG6 Plus Power DC 100 METER

Product Parameter:
Conductor : Copper Clad Steel
AWG(mm) :18(1.02)
Dielectric : Insulation Foam PE
Diameter(mm) :4.57±0.1
Inner Shield :Bonded Aluminum Foil
Inner Braid :36AWG Aluminum 0.12X128
Jacket :PVC RoHS UV
Diameter(mm) :6.86±0.

Power Cable:
Conductor Copper Clad Aluminum
AWG(mm) 7X0.37mm
Dielectric Insulation Red & Black PE
Diameter(mm) 1.80±0.05mm
Jacket PVC RoHS UV
Diameter(mm) 3.3-4.6mm
Impedance(Ohms) 75±3
Velocity of Propagation(%) 83
UV stability UV
Voltage Rating < 80V
Structural Return Loss(dB) 5-1000>20, 1001-3000>16
