Detail Joystick Arduino HW-504 PS2 Robotic Controller Module
12 BFeatures:
Game joystick module for Arduino PS2, electronic building blocks standard connector with 2.54mm pin.
DO port for digital output, AO port for analog output.
Bi directional 10 k resistor, the resistance changes with the rocker in a different direction.
Module uses 5V power supply, the original state of X, Y read voltage of 2.5 V. When pressing at the arrow direction, voltage increases, maximum is 5 v, at opposite direction of the arrow, the voltage value decreases, minimum is 0 v.
DO port for digital output, AO port for analog output.
Description:
ABS plastic material, reusable and durable
Game joystick module suits for Arduino PS2 , connects to two analog inputs, the robot is at your commands with X,Y control.
It also has a switch that is connected to a digital pin, convenient to use.
Specifications:
Model: HW 504
Material: electronic components
Color: black
Size: 16.5 16.5 2mm
Package included:
1 x JoyStick Breakout module
