Processor Base Frequency 3.90 GHz Cache 3 MB SmartCache Bus Speed 8 GT/s DMI3 TDP 51 W
Memory Specifications Max Memory Size (dependent on memory type) 64 GB Memory Types DDR4-2133/2400, DDR3L-1333/1600 @ 1.35V Max # of Memory Channels 2 ECC Memory Supported No
Graphics Specifications Processor Graphics Intel HD Graphics 630 Graphics Base Frequency 350.00 MHz Graphics Max Dynamic Frequency 1.10 GHz Graphics Video Max Memory 64 GB 4K Support Yes, at 60Hz Max Resolution (HDMI 1.4) 4096x2304@24Hz Max Resolution (DP) 4096x2304@60Hz Max Resolution (eDP - Integrated Flat Panel) 4096x2304@60Hz
Package Specifications Sockets Supported FCLGA1151 Max CPU Configuration 1 Thermal Solution Specification PCG 2015C (65W) TJUNCTION 100C Package Size 37.5mm x 37.5mm
