INDICATOR TIMBANGAN A7

Detail INDICATOR TIMBANGAN A7

INDICATOR A7

TYPE : A7

Specification
Accuracy Grade: Class
A/D converting theory and sampling rate: double integration, 10-15 times/time
Maximum inner codes: 500000 codes/time
Non-linearity: 0.01% F.S.
Stimulating voltage for the loadcell: DC +8V, the maximum input signal is about 16 mV
Loadcell quantity: 1 load cell, 4 pins, (no long distance compensation)
Temperature coefficient on F.S: 8 PPM/C
Display: 6-bit LED, 0.56 inches in height, 6 status indicating lights, 3 battery charges
indicating lights
Keyboard: 5 slight-touch keys
Power supply: (1) AC 187-242 V, 50 HZ
(2) Built-in chargable battery 6V, 2.8 AH (2 pcs in serial connection)
Operating temperature and humidity: 0-40C, 90% RH
Storage temperature: -20--+50C
Fuse: 500mA
External dimension: 265 190 170mm
weight: 1.53kg (not including the battery)

Gambar produk
