In Stock SCULPFUN S10 Mesin Ukir Laser 10W Pengukir Laser density Tinggi-speed Air Assist Industrial-grade Carving Precision 410x400mm Engraving Area All-metal structur

Detail In Stock SCULPFUN S10 Mesin Ukir Laser 10W Pengukir Laser density Tinggi-speed Air Assist Industrial-grade Carving Precision 410x400mm Engraving Area All-metal structur

Features:
10W laser Beam Shaping Technology: The S10 laser output power is increased to 10W, which is twice that of the S9.  But S10 obtains the same ultra-thin laser beam with 0.08mm focus as S9, which means S10 has higher energy density, stronger cutting penetration and engraving capabilities.
Powerful High-speed Air Assist: Equipped with a high-speed air assist nozzle. Advanced fluid mechanics design to better utilize the air pressure. When using the same air compressor, the S10 spray airflow faster. For example, when using 30L/min, 0.03Mpa air compressor, the S10 nozzle will spray high-speed airflow up to 14.5m/s. This will greatly improve the cutting penetration and cutting efficiency.
Industrial-grade Cutting Accuracy: S10 adopts industrial high-precision linear slide rail X-axis, which makes it get industrial-grade engraving accuracy. When comparing the small engraving details, S10 does not have the wave lines that other ordinary engraving machines appear.
More Advanced and Upgradable 32-bit Motherboard: The S10 motherboard uses 32-bit chips, with faster computing speed, and it still reserves Z-axis and limit switch functions to facilitate people to upgrade the engraving machine. It still perfectly supports laser cutting software like Lightburn and LaserGRBL.
Square Measuring Ruler: X-axis and Y-axis contain precise scale lines, which is convenient for you to measure the size of engraving objects quickly. The 400x400mm large-area engraving interval can meet your various engraving needs.
Detachable Laser Shield & Safe Design: Equipped with a detachable eye shield, which will not dazzle even without glasses. And if you don't need it, you can easily disassemble the eye shield. There is a very safe and eye-catching power switch on the machine, you can directly and quickly turn off the power in an emergency. The all-metal body makes the machine very sturdy and durable. And the free A4 size steel pad can protect the table from laser damage, isolate fire hazards.
Specification:
Model: S10
Diode Laser Output Power: 10W (Note This Is Light Energy Not Electrical Energy)
Inner Diameter Of Air Pipe: 7.5mm (Recommended To Use 30L/Min, 0.03mpa Air Compressor, Out Diameter Of Nozzle: 8mm)
Laser Wavelength: 455±5nm
Engraving Accuracy: 0.01mm
Engraving Area Size: 410x400mm
Focusing Method: Fixed Focus + Sliding Device
Laser Protection Cover: Equipped With a Detachable Laser Cover To Protect The Eyes. You Can Adjust It Up And Down, Or Remove The Cover
Machine Power Consumption: About 36W (Not Related To Engraving Or Cutting Performance, Just Power Consumption)
Engraving/Cutting Materials:
Engraving Material: All Kinds Of Wood (Including Walnut, Cherry And Other High Density Wood), MDF, Bamboo, Cardboard, Plastic, Leather, PCB Board, Alumina, 304 Stainless Steel, Ceramic, Dark Stone
Cutting Material: All Kinds Of Wood (Including Walnut, Cherry And Other High-Density Wood), MDF, Acrylic, Cardboard, Bamboo, Some Plastic Boards, Leather, PC
