ICOM IC-M323G VHF Marine Fixed DSC with built-in GPS

Detail ICOM IC-M323G VHF Marine Fixed DSC with built-in GPS

Output Power: 25W
GPS:Supplied external GPS antenna (G version)
Waterproof Rating:IPX7
Versions:Black or Super White

With or without GPS
GPS Capability
The M330G includes a GPS receiver and an easy to install external GPS puck antenna for better accuracy and performance. The small compact GPS puck antenna provides your location, bearing and speed by using information from GPS, GLONASS and SBAS. This information is used for DSC (Digital Selective Calling) calls. Hook up the GPS puck antenna for the most accurate GPS and DSC functionality to work.

Compact and Easy to Use
The M330s small size makes it easy to install into vessels with limited space. The dot-matrix display is clear and easy to read. A combination of the directional keypad and soft keys provides simple, smooth operation. Most used functions are assigned to soft keys for quick one push function access.

Additional Features
AquaQuake draining function
Built-in Class D DSC with a CH70 dedicated receiver
Common NMEA interface for external GPS/NAV connection
Tag scan and favorite channel functions
Dual/tri-watch function for monitoring CH16 and/or call channel
Priority scan function
Display and keypad backlighting
Weather channel with weather alert
3-digit or 4-digit channel display selectable


ICOM IC-M330G VHF MARINE SPECIFICATIONS
General
Frequency Range
Tx :156.025161.600MHz
Rx : 156.050163.275MHz
Ch. 70 : 156.525MHz

Usable channels USA, CAN, INT, WX channels
Type of emission 16K0G3E (FM)
16KOG2B (DSC)
Power supply requirement 13.8V DC nominal (11.715.9V DC)
Current drain (at 13.8V DC)
Tx 25W output
Rx AF max.
5A
1A
Operating temperature range

-20C to +60C; -4F to +140F

Antenna Impedance 50 (SO-239)
Dimensions (WHD)
(Projections not included) 156.5 66.5 110.1 mm;
6.2 2.6 4.3 in
Weight (approx.) 730g; 1.6lb
NMEA formats
In
Out
RMC, GGA, GNS, GLL, VTG
DSC, DSE, RMC, GSA, GSV
Transmitter
Output power (at 13.8V DC)
25W, 1W

Max. frequency deviation 5 KHz
Frequency tolerance 5 ppm
Spurious emission
