Detail IC SN74HC04N DIP-14 Texas Instruments SN74HC04 74HC04

Hi #RekanEasyWare ...
EasyWare Part#: EP001183

*******Bismillah*******

Texas Instruments range of Inverters and Buffers from the 74HC Family of CMOS Logic ICs.
The 74HC Family use silicon gate CMOS technology to achieve operating speeds similar to
the LSTTL family but with the low power consumption of standard CMOS integrated circuits.

Detail:
- Wide Operating Voltage Range of 2 V to 6 V
- Outputs Can Drive up to 10 LSTTL Loads
- Low Power Consumption, 20-µA Maximum ICC
- Typical tpd = 8 ns
- ±4-mA Output Drive at 5 V
- Low Input Current of 1 µA Maximum
- The SNx4HC04 devices contain six independent inverters. They perform the Boolean function Y = A in positive logic.

Package:
1 x IC SN74HC04N texas Instruments
