HXJ8002 AMPLIFIER MINI 3W Mono Single Channel Audio 5V HXJ 8002 Hi Fi

Detail HXJ8002 AMPLIFIER MINI 3W Mono Single Channel Audio 5V HXJ 8002 Hi Fi

HXJ8002 Mini Audio Power Amplifier Board Mono Channel Voice low noise Amplifiers Module 2.0-5.5V Replace PAM8403

This module is ideally suited to adding a bit of amplification to your audio outputs. Connecting your audio inputs and a separate power 2 - 5.5V supply allows you to amplify an audio line in preparation to be connected up to a speaker. This module is ideal for situations where a device is unable to drive with sufficient volume or in instances where an audio signal has been split across multiple outputs, such as using a splitter.

Onboard HXJ8002 single channel 3W, BTL bridge connected audio power amplifier chip.
Operating voltage: 2.0-5.5V.
Standby Current: 0.6uA (typ).
The input signal frequency is 1kHz, 8Ohm load, the average output power under 1W maximum distortion is 0.5%.
In THD + D Less than 10%, input 1KHZ frequency, different load conditions of output power (typical value): 3W (load 3Ohm); 2.5W (load 4Ohm); 1.5W (load 8Ohm).
Model: HXJ8002.
Size: 20*14*3mm(L*W*H).
Weight: 1.1g.

Pin Description
VCC：2 - 5.5V
GND：0V
L：Left channel input
GND：0V Input
R：Right channel input
V1：Speaker connection
V2：Speaker connection
