HT ALINCO DJ W35 UHF 350MHz - HT UHF LOW ALINCO DJ W35 DJ-W35 UHF 350 -390MHz MURAH

Detail HT ALINCO DJ W35 UHF 350MHz - HT UHF LOW ALINCO DJ W35 DJ-W35 UHF 350 -390MHz MURAH

Alinco DJ-W35 power 4 Watt menggunakan battery Lithium /


Specifications Alinco DJ-W35 :

Frequency coverage : (TX/RX) 350.000-399.995MHz (RX only) 76-108MHz
Mode : F3E(16K0F3E / 11K0F3E / RX only WFM)

Programmable channels : 128 channels
Frequency stability : 2.5ppm

Power supply requirement : 7.4V DC20% (negative ground)
Current drain (Approx.) : 1400mA TX / 300mA receive at Max audio output / 70 mA squelched
Usable temperature range : -20~ +55C(-4~131F)

Dimensions (Projections not included/approx.) : 599835 mm

Weight : approx.227g or 8.01oz inclusive of battery pack and antenna
Transmitter (ETSI EN300 086 compliant)

Output power : Approx.4 / 2 / 0.5W
Modulation system : Variable reactance FM
Spurious emissions : Less than -36dBm
Max. frequency deviation : 5kHz / 2.5kHz
Receiver :(ETSI EN300 086 compliant)

Receive system : Doble conversion superheterodyne
Intermediate frequencies : 26.45MHZ
Sensitivity(12dB SINAD Wide/Narrow) : -12dB or better (0.25V/0.35V) or better
Selectivity : -6dB : -6dB : Wide 12kHz /Narrow 10kHz or more -60dB :Wide 30kHz / Narrow 24kHz or less
Audio output power : 1000mW(10% distortion)

Standart Include :
* Unit HT
* Battery
* Antena
* Belt Clip (Cantelan Batre)
* Manual book
* Charger & Adaptor

GARANSI 1 TAHUN

Gambar produk
