ALINCO DJ-W35 GARANSI RESMI 1 TAHUN

Specifications Alinco DJ-W35

Frequency coverage : (TX/RX) 350.000-399.995MHz (RX only) 76-108MHz
Mode : F3E(16K0F3E / 11K0F3E / RX only WFM)
Programmable channels : 128 channels
Frequency stability : ±2.5ppm
Power supply requirement : 7.4V DC±20% (negative ground)
Current drain (Approx.) : 1400mA TX / 300mA receive at Max audio output / 70 mA squelched
Usable temperature range : -20~ +55°C(-4~131°F)
Dimensions (Projections not included/approx.) : 59×98×35 mm
Weight : approx.227g or 8.01oz inclusive of battery pack and antenna


Transmitter (ETSI EN300 086 compliant)

Output power : Approx.4 / 2 / 0.5W
Modulation system : Variable reactance FM
Spurious emissions : Less than -36dBm
Max. frequency deviation : ±5kHz / ±2.5kHz
Receiver :(ETSI EN300 086 compliant)


Receive system : Double conversion superheterodyne

Intermediate frequencies : 26.45MHZ
Sensitivity(12dB SINAD Wide/Narrow) : -12dBµ or better (0.25µV/0.35µV) or better
Selectivity : -6dB : -6dB : Wide 12kHz /Narrow 10kHz or more -60dB :Wide 30kHz / Narrow 24kHz or less
Audio output power : 1000mW(10% distortion)
