HQ IC card reader Ming Wah URF-R330 IC Card Reader M1 Ka Mingtai USB

Detail HQ IC card reader Ming Wah URF-R330 IC Card Reader M1 Ka Mingtai USB

hai kak. Mohon maaf untuk minimal order 20 ribu ya kak baru bisa kita proses, diluar ongkirURF-R330 IC card reader
product manual:
Standard Features
USB full-speed (12 Mbps), no driver
Support USB hot swap
Provide power, data communication indicator
* Comply with CE, FCC, RoHS
Non-contact interface IC reader
- Support for compliance with ISO 14443 standard Class A cards
- MIFARE one card dedicated reader
Technical Specifications
Computer Interface
standard
USB 1.1
power supply
USB to take power
rate
12Mbps (full speed)
Operating Voltage
5V
Electric current
200mA (work); 50mA (standby); 100mA (General)
Contactless smart card interface
Standard protocols
ISO14443 TypeA
Operating frequency
13.56MHZ
Smart card read / write rate
106/212/424 kbps
Operating distance
0-25mm
HMI
Lights
Power, data communication indicator
Green indicator light indicates that the card reader blinks to indicate
communication
Blue LED reserved for future use
buzzer
Monotonous tone
Overpack
size
135 mm (length) x 79 mm (width) x 13 mm (height)
Colour
Silver
Cable
length
1.5 m
Standards / Certifications
Authenticate
Comply with CE, FCC, RoHS
Environmental requirements
Operating temperature
0 ~ 50 C
Supported operating systems
Supported operating systems
Windows 2000, XP 32, XP64, Vista 32 and Vista 64
