HQ Angle sensor module tilt sensor ball switch

Detail HQ Angle sensor module tilt sensor ball switch

hai kak. Mohon maaf untuk minimal order 20 ribu ya kak baru bisa kita proses, diluar ongkirstock = 10 pcs

use:

Tilt a variety of products, dumping an alarm is triggered, dumping off the
sensor, tilt sensor.

Module Features:
1, the use of highly sensitive angle switch SW-520D as a sensor, tilt sensor can
also be used for other functions in the following link sensor, a friend in need,
please apply for a change, will change the appropriate price:
fcswitchtaobaocom/search .htm? SCID = 528 059 724 = & scname vce2yLSruNDG9w% 3D%
3D & checkedRange = queryType to true & CAT =
2, the comparator output signal clean, good waveform, driving ability over 15mA.
3, the working voltage of 5V-3.3V
4, output forms: Digital switching output (0 and 1)
5, a fixed bolt hole for easy installation
6, small PCB board size: 3.2cm X 1.4cm
. 7, using a wide voltage LM393 the comparator
module for use
1, the wiring of the module wiring diagram see below, is described in detail;
2, switch module outputs depends on the angle of the switch is turned on and
off, and when the angle switch is turned off, DO output high when the level of
the angle switch is turned on, DO output low;
3, the output can be directly connected to the microcontroller through the
microcontroller to detect high and low, thereby detecting the angle of change;
4, outputs can directly drive a relay module, It can form a powerful angle
switching, protection of electrical equipment and other products dumped
automatic power-off function

Gambar produk
