24 autosensing 10/100 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX); Media Type: Auto-MDIX; Duplex: half or full
1 RJ-45 serial console port
2 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only 2 open mini-GBIC (SFP) slots
L2 switching '' VLANs Provide support for 512 VLANs and 4,094 VLAN IDs '' Jumbo packet support Improves the performance of large data transfers; and supports frame sizes up to 9,220 bytes '' IEEE 802.1v protocol VLANs Isolate select non-IPv4 protocols automatically into their own VLANs '' Per-VLAN spanning tree plus (PVST+) Allows each VLAN to build a separate spanning tree, improving link bandwidth usage in network environments with multiple VLANs
L3 routing '' Static IP routing Provides manually configured routing; and includes the ECMP capability '' Routing information protocol (RIP) Provides RIPv1 and RIPv2 routing
Dimensions 17.44(w) x 10(d) x 1.73(h) in (44.3 x 25.4 x 4.39 cm) (1U height)
