HP PROCURVE SWITCH 2524 J4813A

Detail HP PROCURVE SWITCH 2524 J4813A

GENERAL
Subtype Fast Ethernet
Ports 24 x 10/100
Authentication Method RADIUS, Secure Shell (SSH), TACACS+
Flash Memory 2 MB flash
MAC Address Table Size 4K entries
Authentication Method Secure Shell (SSH), RADIUS, TACACS+
Routing Protocol IGMPv3
ManufacturerHP
CAMERA
Installed Size 2 MB
EXPANSION / CONNECTIVITY
Installed Modules Qty (Max) 0 (installed) / 2 (max)
NETWORKING
Cabling Type Ethernet 100Base-TX, Ethernet 10Base-T
MAC Address Table Size 4K entries
Subcategory network hubs and switches
Subtype Fast Ethernet
Form Factor rack-mountable
Type Switch
Stackable stackable
Connectivity Technology wired
Features Cisco Fast EtherChannel, VLAN support, auto-sensing per device, auto-uplink (auto MDI/MDI-X), flow control, manageable, stackable
Compliant Standards IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad (LACP), IEEE 802.3u, IEEE 802.3x
Ports Qty 24
Manageable Yes
Routing Protocol IGMPv3
Switching Protocol Ethernet
Remote Management Protocol HTTP, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2c
POWER DEVICE
Nominal Voltage AC 120/230 V
Frequency Required 50/60 Hz
Power Consumption Operational 36 Watt
Type internal power supply
POWER
Power Device Internal power supply
PROCESSOR
Type ARM7TDMI
Installed Qty 1
Clock Speed 62.5 MHz
MISCELLANEOUS
Compliant Standards FCC Class A certified, CSA, CISPR 22 Class A, CISPR 24, cUL, EN 60950, EN 61000-3-2, EN50082, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC950, NOM, UL 1950, VCCI Class A ITE, EN 61000-3-3, EN55024, EN55022 Class A, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3
Rack Mounting Kit included
Height (Rack Units) 1 m
INTERFACE PROVIDED
Qty 1, 24
