Camera Image Sensor 8.29 megapixel progressive scan CMOS Max. Resolution 3840 (H) × 2160 (V) Min. Illumination Color: 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR Shutter Time PAL: 1/12.5 s to 1/50,000 s,NTSC: 1/15 s to 1/50,000 s Day & Night IR cut filter Angle Adjustment Pan: 0° to 360°, Tilt:0° to 75°, Rotate: 0° to 360° Signal System PAL/NTSC Lens Lens Type 2.8 mm, 3.6 mm, 6 mm, 8 mm, 12 mm fixed lens Focal Length & FOV 102.2° (2.8 mm), 79° (3.6 mm), 50.8° (6 mm), 37.73° (8 mm), 23.96° (12 mm) Lens Mount M16 Image Image Settings Brightness, Sharpness, DNR, Smart IR, HLC Frame Rate TVI: 8MP@12.5fps, 8MP@15fps, 4MP@25fps, 4MP@30fps, 2MP@25fps, 2MP@30fps,CVI: 8MP@12.5fps, 8MP@15fps,AHD: 8M@12.5fps, 8M@15fps,CVBS: 960H P/N Day/Night Mode Auto/Color/BW (Black and White) Wide Dynamic Range (WDR) Digital WDR/ 105 dB Image Enhancement BLC White Balance Auto/Manual AGC Yes Interface Video Output Switchable TVI/AHD/CVI/CVBS General Material Enclosure: Plastic,Main body: Metal Dimension Ø 109.82 mm × 91.03 mm (Ø 4.32" × 3.6" ) Approx. 320 g (0.71 lb.) Operating Condition -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation) Communication Up the coax, Protocol: HIKVISION-C (TVI output) Language English Power Supply 12 VDC ±25%,*You are recommended to use one power adapter to supply the power for one camera. Consumption Max. 5.3 W IR Range Up to 60 m Approval Protection IP67
