Detail //HG&ID// 40PCS 3 Pin SS12D00G3 2 Position SPDT 1P2T PCB Panel Mini Vertical Slide Switch .

Specifications:

Product Name : Slide Switch

Model : SS-12D00G3

Type : 1 Pole 2 Throw

Terminal Quantity : 3 Pcs

Working Power : 0.5A 50V DC

Contact Resistance : 30mΩ Max

Insulation Resistance : 100mΩ Min at 500V DC

Withstand Voltage : AC 500V for 1 min

Terminal Length : 3mm/ 0.12"

Pin Pitch : 2.54mm / 1"

Main Body Size(not include Pins & Knob) : 8 x 4 x 3.8mm/ 0.31" x 0.16" x 0.15"(L*W*H)

Switch Total Size : 8 x 4 x 10mm/ 0.31" x 0.16" x 0.39"(L*W*H)

Knob Size : 1.5 x 1.5 x 3mm/ 0.06" x 0.06" x 0.12"(L*W*H)

Material(External) : Plastic, Metal

Main Color : Silver Tone, Black
