Detail [HeavenDenotation] Sensor Pendekatan LJ12A3-4-Z/AY LJ12A3-2-Z/AX inductive proximity sensor switch HDV

Parameter Utama Utama, Parameter Utama,
Jarak Deteksi: 4mm ± 10% 10%
Atur jarak: 0~3.6mmmmmmmmmmmmmm
Arus: 5V 360mA, 12V 200mA, 24V 96mA, arus instan maksimum 2A
Jarak lengah: 10% dibawah pengesanan jarak jauh
Deteksi objek: Logam magnetik (jarak deteksi menurun ketika non-ic metal)
Objek deteksi berdiri: Besi 15*1mmmm 1mm
Frekuensi Respons: DC:0.5kHz
Tegangan pasokan: jenis DC: DC12V DC24V DC36V (5~36V)impulse (p-p)10% di bawah ini
Tahan tegangan: AC1000V 50/60Hz 1min antara bagian pengisian dan perumahan
Meterial: (Rumah: Kuningan berlapis nikel) (Permukaan deteksi:ABS)
Pengaruh Perlindungan: Spesifikasi IP67 (IEC)
Produk ini dapat diterapkan untuk mengontrol relai, penghitung, PLC, dll.!! Produk ini dapat diterapkan untuk mengontrol relai, penghitung, PLC, dll.!
