HDMI SPLITTER 4 PORT 4Kx2K HDMI Splitter 1x4 3D 4 Port HDCP XGA

Detail HDMI SPLITTER 4 PORT 4Kx2K HDMI Splitter 1x4 3D 4 Port HDCP XGA

SPLITH 1040

4K x 2K HDMI Splitter 1x4 3D 4 Port HDCP XGA VGA SXGA SVGA UXGA

The HDMI Splitter 1x4 use a single HDMI source,accessing to 4 HDMI sinks.The Splitter allows one HDMI devices to be split easily to 4 HDMI compatible monitors or projectors. The Splitter can also be placed at the end of a long HDMI cable to regenerate the HDMI signal.

Features:
1. One HDMI input signal split to two HDMI sink devices
2. Support Full HD, Full 3D
3. Support up to 1080P
4. Support deep color 30bit, 36bit
5. Support Blue-Ray 24/50/60fs/HD-DVD/xvYCC
6. Digital audio format, as DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/DSD/HD(HBR)
7. Support signal retiming
8. Support input up to 12metres AWG26 HDMI standard cable length, output up to 20metres AWG26 cable length(when the resolution is 4k,input up to 8 meters ,output up to12 meters.
9. No loss of quality

Specification:

Max Single Link Range : 1920X1200, 1080P
Output Video HDMI : 1.3 + HDCP1.0/1.1/1.2
Resolutions DTV/HDTV : 480i/576i/480p/576p/720p/1080i/1080PHDCP versionHDCP1.2
HDMI Version HDMI : 1.3V
Operating Frequency : Up to 225MHzEIDI Duration 4 seconds
Operating Temperature range : (-15 to +55°C)
Power adapter format : Input:AC (50HZ, 60HZ) 100V-240V; Output: DC5V
Operating Humidity range : 5 to 90%RH (No Condensation)
Max. cable extension : 10 meters by 28AWG HDMI cable; 15 meters by 26AWG HDMI cable
