Hardwell AT1 Antena Distributor Sinyal Mic Wireless

Detail Hardwell AT1 Antena Distributor Sinyal Mic Wireless

Antena wireless penambah jarak jangkauan microphone wireless
Model: Hardwell AT 1 (ORIGINAL)
Perlengkapan:
- 1 unit receiver
- 2 unit sirip antena
- 2 unit kabel conector dari receiver ke sirip antena panjang kisaran 2 meter
- 8 unit kabel conector antena dari receiver Hardwell AT 1 ke receiver mic wireless Lain
- 4 unit kabel adaptor untuk microphone wireless lain
- 1 unit adaptor
- FREE Hardcase

Spesifikasi:
DIRECTIONAL ANTENNA TECHNOLOGY INDEX:
- Antena type : Log periodic dipole array ( LPDA ) antenna
- The working frequency band : 500 MHz - 1 GHz
- Working voltage: 8V DC
- Gain: 6dB typical, maximum 10 dB
- Impedence: 50 typical
- VSWR : 1.7.1
- Direction: Oval typical
- Direction polarity: Vertical
- Number of segments for wave guides : 11 segments
- Connectinf terminal: Fixed right - angel BNC pcb jack
- Weight: 310 gram
- Dimension: 348 mm x 325 mm x 25 mm
- Structure: glass copper and copper film coating
- Coating: dusky black

ANTENNA DISTRIBUTION AMPLIFIER TECHNOLOGY INDEX ( Receiver )
- Antenna distributor: one divided to two / one divided to four
- The working frequency band : 500 MHz - 1GHz
- Gain : 6-10 dB
- Working voltage: DC 12V 12A / DC 12V 3A
- The output of external power supply: DC 12V 800 MA

Gambar produk
