Zotek VC17B+ Autorange Digital Multimeter.
*Include probe temperature
*Pengukuran arus sampai 20A
*Mode Min Max
*Auto range / Manual range mode
*Backlight ON/OFF
*Ukuran lebih besar 180*90.5*45mm



Features:
100% brand new and high quality.
Automatic / manual range.
True RMS measurement.
Resistance capacitance frequency file high voltage 550V protective.
Large screen display, the maximum of 6000 words.
Sampling rate: about 3 times per second.
Backlight display.
Maximum / minimum value hold.
Polarity automatic recognition.
Low voltage display.
20A large current measurement.
Automatic shutdown.
Main measurement: AC / DC voltage, AC / DC current, resistance, capacitance, diode / off measurement, temperature measurement, frequency and duty ratio measurement.

Specifications:
Frequency: 5/50/500/5k/50k/500k/5M/10M (+ 0.1+3)
Temperature: less than 400 degrees Celsius + (1.0%+5), more than 400 DEG C + (1.5%+15)< 752 + (1.0%+5), more than 752 degrees Fahrenheit (1.5%+15).
Capacitance: 10nF (+ 5.0+20), 100nF/1uF/10uF/100uF (+ 2.0%+5), 1000uF/10000uF (+ 5.0%+5)
DC voltage: 600mV (+ 1.0%+10), 6V/60V/600V/1000V (+ 0.5%+3)
AC voltage: 600mV (+ 3.0%+3), 6V/60V/600V/750V (+ 1.0%+3)
Resistance: 600 (+ 0.5%+3), 6K/60K/600K/6M (+ 0.5%+2), 60M (+ 1.5%+3)
Share wide ratio: 1% to 99% (+ 1%)
Measurement mode: double integral A/D converter
Ultra range display: OL
Working environment: 0~40 C, relative humidity < 80%
Supply voltage: 3V (AA x2 Pcs 1.5V)
Size: 180*90.5*45mm
Package size: 200*125*53mm
Color: black

Package included:
1 x multimeter
1 x User manual
1 x 1 pair probe
1 x Temperature probe head
Battery tidak terdapat pada bawaan pabrik
