GY-BME280-5V Temperature and Humidity Sensor GY BME280 5V

Elektronik > Elektronik Lainnya > GY-BME280-5V Temperature and Humidity Sensor GY BME280 5V
  • Pengiriman Ekspres
  • Barang yang diperiksa
  • Bayar di tempat berlaku
  • Kualitas, Prestise
  • Pengembalian produk
  • Dukung pembuatan faktur

Detail GY-BME280-5V Temperature and Humidity Sensor GY BME280 5V

Hi #RekanEasyWare ...
EasyWare Part#: EP000879

Board Mount Humidity Sensors The BME280 is an integrated environmental sensor developed specifically for mobile applications where size and low power consumption are key design constraints.

Note:
- Foto real stok EasyWare Electronics.

Fitur:
- The BME280 is a great new chip that was originally designed for the next generation of smartphones.
- With an I2C connection, you have access to enough weather data to make some pretty good predictions for your local area.
- BME280, the precision sensor, is soldered onto PCB.
- Not only the pressure and the temperature, but this sensor can also measure humidity.
- It uses both I2C and SPI (supports 3-, 4-wire SPI) interface

Spesifikasi:

- Operating Voltage (VDC): 1.8 - 5V
- Interface: I2C (up to 3.4MHz) / SPI (up to 10 MHz)
- Operating Humidity Range: 0-100%
- Operating Pressure Range: 300-1100 hPa
- Resolution: Temperature: +-1°C ; Humidity: +-3% ; Pressure: +-1Pa
- I2C Address: SDO LOW: 0x76 ; SDO HIGH: 0x77

Kelengkapan:
1x GY-BME280 5V High Precision Barometric Module

Gambar produk

GY-BME280-5V Temperature and Humidity Sensor GY BME280 5V
GY-BME280-5V Temperature and Humidity Sensor GY BME280 5V
GY-BME280-5V Temperature and Humidity Sensor GY BME280 5V
GY-BME280-5V Temperature and Humidity Sensor GY BME280 5V
