Detail GY-6500 MPU6500 MPU-6500 6DOF 6 axis gyro accelerometer sensor Module

Deskripsi Produk
Notice: The new tracking number for China Post Ordinary Small Packet Plus only can track it have been ship out of China, not more Tracking information ,even it arrived or not .
Please do not freeloaders,if you can not accept without more tracking information .
Please choose China Post Air Mail if you want a full tracking info.
Tracking info of China Post Ordinary Small Packet Plus can be check here : www17tracknet/en
MPU-6500 module (three-axis gyroscope + triaxial accelerometer)
Module Model: GY-6500
Use chip: MPU-6500
Power supply: 3-5v (internal low dropout regulator)
Communication: standard IIC / SPI communications protocol
-Chip 16bit AD converter, 16-bit data output
Gyroscopes range: 250 500 1000 2000 / s
Acceleration range: 2 4 8 16g
The use of Immersion Gold PCB, machine welding process to ensure quality
2.54mm pitch
Module size 15mm * 25mm
