Genset Diesel IWATA 10Kva Silent - IW10WS

Detail Genset Diesel IWATA 10Kva Silent - IW10WS

Setiap hari buka termasuk hari minggu/libur, silahkan di pesan barangnya dan kami akan mengirimkan barang pesanan anda secepat mungkin

Mohon Tanyakan Stock terlebih dahulu sebelum Melakukan Order !!
Untuk menghindari Penolakan Order, Mohon Tanyakan Stock terlebih dahulu sebelum Melakukan Order !!

Heavy Duty Class Genset, Taiwan
Model : IW10WS (Silent Type)
Smart Controller : Deepsea-DSE6020 (Made in UK)
Rated Power / Max Power : 10kw / 11Kw
Rated Voltage/ Rated Current : 230V / 43.5A/ 1 Phase
Rated Speed r/min : 1500, Frequency (Hz) : 50
Start Mode : 12v, Noise level (dB(A)7m) : 66
Fuel tank capacity (L) : 45
Operational time on single tank fuel : ±18 Hours
Engine manufacturer : IWATA, Model : 480D
Bore x Stroke : 85*90mm
Displacement : 1.81L, 12hrs Power (kw) : 14
Fuel consumption : ±2.5 L/h
Engine Type : Water cooled , 4-stroke,Direct injection
Cylinder No. : 4, Compression Ratio : 17:1
Starting Motor (V-W) : 12V-3KW, Charging alternator (V-W): 14V-500W
Alternator Spec Circulated type : 1Phase, 4 wires , Y type connection
Excitation mode : Brushless Self-Excitation and constant voltage (AVR)
Power factor cosθ : 1( lag), Pole number : 4 Over
Excitation Protection : IP23 , Insulation : H
Voltage Regulator : AVR SX460, Voltage Regulator : NL-FL ±5%
Dimension L.W.H (mm) : 1650*780*950
Coating System : Heavy Duty Powder Coating, Outdoor Grade
Net Weight(KG) : 650kgs
Features :
• Deepsea smart controller Made in UK (England)
• Heavy Duty Engine from Iwata
• Outdoor grade Genset application
• 3 Years Warranty
• 20 Years spareparts availability


Harga Terbaik : CALL SALES

#Harga diatas sudah termasuk PPn
#Kami akan menerbitkan faktur pajak setelah transaksi

Dapatkan produk-produk berkualitas tinggi dengan harga yang ekonomis.
Hati-hati barang tiruan, Produk yang asli hanya ada di PT. Indotara Persada.
