Gas Detektor LPG Bocor Alarm Standalone

Elektronik > Kelistrikan > Alarm > Gas Detektor LPG Bocor Alarm Standalone
  • Pengiriman Ekspres
  • Barang yang diperiksa
  • Bayar di tempat berlaku
  • Kualitas, Prestise
  • Pengembalian produk
  • Dukung pembuatan faktur

Detail Gas Detektor LPG Bocor Alarm Standalone


Video perkenalan produk Gas Detektor LPG Bocor Alarm Standalone. Sumber: Shopee.

READY STOK
Gosend Ready, Brg sdh dicheck sblm kirim, Selalu dikirim di hari yg sama sblm jam 19.00 setiap hari bahkan tgl merah.

READY STOK
Alarm Kebocoran Gas Detector Standalone colokan Indonesia bulat

Saran Pemasangan: 1.5 m dari tempat masak
Berat 160gr
LED INFO:
RED LED Flash: Gas Leaking
RED LED On: Sensor failure
GREEN LED On: Normal Working
GREEN LED Flash: Warm up inside sensor

Specification :
- Power source : 220 VAC
- Sensitivity : Propane LEL : 2,1 Vol % / HEL(UEL) : 9,5 Vol%
- Butane LEL : 1,8 Vol% / HEL(UEL) : 8,4 Vol%
- Methane LEL : 5,0 Vol% / HEL(UEL) : 15,0 Vol%
- Power Consumption : 1,7 Watt
- Operating Temperature : (-10) Celcius - (50) Celcius
- Ambient Humidity : Less than 95% RH
- Horn Level : 75 Decibles at 10 feet
- Standby Mode : Green LED on
- Alarm Mode : Red LED flashes and an acoustic alarm.
- Type Of Gas Sensed : Natural Gas, Town Gas, LPG
- Size : 110x69x36 mm
- Weight : 320g
- Package : 43x110x142 mm

Aplication :
- Mounted on the wallor cabinet, about 30 cm aboe the ground for LPG or about 30 cm bellow ceiling for coal gas & natural gas use.
- Ventilation hole showed as sketch map should be installed down
- After power on, the relay output stop, the green indicator shall be flashed for preheating od sensor which is not in the normal operation of detectin.
- After 3-4 mnutes, the green indicator shall be stopped flash and the relay output shall be closed for normal operation of detection.
- When the ignitable gas is detected, the red indicatro shall be flash with alarm sound, after 10 second the relay output is open until the ignitable gas disappears.
- If sensor is invalis, the red indicator will be light and with the alarm sound continuos.

SYARAT PENGEMBALIAN PRODUK:
~TIDAK MENERIMA PENGAJUAN KOMPLEN DGN BUKTI FOTO,
~WAJIB LAMPIRKAN VIDEO UNBOXING/ BUKA PAKET & JELASKAN LGS APA YG DIKOMPLEN DGN JELAS
