Gamepad wireless ipega single turbo mini vibration pg-sw022 - Joystick bluetooth controller

Detail Gamepad wireless ipega single turbo mini vibration pg-sw022 - Joystick bluetooth controller

Feature
-This handle is suitable for operating games for N-S/P3/Android and computer (Win7 and above) devices.
-The function buttons of this handle correspond to the button functions of for N-S Pro handle one by one, and support the TURBO function.
-This handle supports vibration and six-axis functions, so that players can get a better gaming experience.
-Ergonomic structure, comfortable hand feeling.

Specification
Working Voltage: DC3.7V
Working Current: <30mA
Quiescent Current: <20μA
Continuous Use Time: >15H
Input Voltage/Current: DC 5V/500mA
Charging Time: About 3H
Wireless 3.0, Transmission Distance: ≤8m/26.25ft
Battery Capacity: 380mAh
Standby Time: 30 Days When Fully Charged

instruction
N-switch
-Connect the handle to the host for the first time: Open for N-S host, touch and click with your finger on the main interface for N-S host: handle - Change the grip/order and enter the host pairing mode interface.
-When the handle is off, press the B+HOME key combination for 2 seconds to turn on the handle and enter the pairing mode. The LED2 light on the handle starts to flash in a rapid cycle. When a single or multiple LEDs are always on (the host is automatically assigned), the handle and the host is successfully paired, and then press the A key to operate.
-Successfully Connected: Long press the HOME button for 2 seconds to turn on the handle, the handle is automatically connected to the host, and then press the A button to operate.

Android
(For Android standard HID mode, note: in Android mode, no vibration function, no six-axis function)
When the handle is off, press the Y+HOME button at the same time for 2 seconds to enter the Android standard game pairing mode, the handle LED1 flashes quickly, when for Android phone/Android tablet/Android smart TV searches for the device name "PG-SW022", select the connection . After the connection is successful, the handle LED1 light is always on. You have successfully connected, you can directly press the HOME button, the LED1 light flashes slowly, and the connection is automatically returned.

PC Wired
-When the handle is off, long press L1+HOME key combination for 2 seconds to turn on the handle, the handle LED4 will flash quickly, and use the USB data cable to connect the handle. Connect to the PC device, at this time it for PC and P3 wired mode, the handle LED2 light is on.
-Long press the home button for 3 seconds to switch for PC Xbox360 mode, at this time the handle LED3 light is on.
-Warm Tip: In wired connection mode, Support vibration function, without six-axis function.

Ps3
-When the handle is off, long press A+HOME key combination to turn on for 2 seconds, and the 4 LED indicators on the handle flash simultaneously.
-Use a USB data cable to connect the handle to for P3 host, and press the HOME button to pair.
-After the pairing is successful, the corresponding channel LED will be on and the handle will enter for P3 mode operation.
-Unplug the USB cable, the handle enter wireless connection
