ftth Visual Fault Locator 10 MW 10Km Fiber Optic Laser Cable Tester

Detail ftth Visual Fault Locator 10 MW 10Km Fiber Optic Laser Cable Tester

Visual Fault Locator 10mW 10km Fiber Optic Laser Cable Tester

Features:
Easy to check fiber faults with visual red laser light FC, SC, ST General interface Sturdy and durable shell Constant output power Long inspection distance Operates in either CW (Continuous wave) or pulse (Both modes are available) Pen pattern design, convenient for use and carry Dust-proof design keeps fiber connectors clean Compact in size, light in weight, red laser output, both SM and MM available.

Introduction:
1. Central wavelength:650nm10nm
2. Emitter type: LD
3. Output power: 10mW
4. Optical connector: 2.5mm universal connector
5. CW frequency: 2Hz
6. Power supply: 2 x AA Alkaline batteries ( not include)
7. Operating temperature: -10~+60
8. Storage temperature: -20~+70
9. Dimension: 168mm*27mm
10. Color: Black Orange & Black Blue

Package Include:
1 x 10mW 10Km Visual Fault Locator Fiber Optic Laser Cable Tester.
1 x Black bag.
