FTTH Splicer SKYCOM T-307H Hi-Precision Digital Fusion Splicer Fiber

Detail FTTH Splicer SKYCOM T-307H Hi-Precision Digital Fusion Splicer Fiber

Fiber Optik Fusion Splicer Fusion Splicer Skycom T-307H Alat penyambung Fiber Optik

- Model: Skycom T-307
- Applicable Fibers: SM, MM, NZ-DS, EDF, Pigtail, Drop Cable (rubber-insulated wire)
- Average Splice Loss: 0.02dB(SM), 0.01dB(MM), 0.04dB(NZDS), 0.04dB(EDF)
- Return Loss: ≥60dB
- Quick splicing time: 8 seconds
- Quick heating time: 25 seconds
- Splicing Program: 50 groups
- Protection Sleeve Length: 40mm, 45mm, 60mm
- Operating Language: Chinese, English, French, Portuguese, Spanish
- Operating Conditions: -10~+50°C(operation temperature),0~95% RH(humidity), 0~5000m(altitude)
- Power Supply: AC input AC adaptor: 100~240V input voltage, 50/60Hz; DC input: 12V, 5A output voltage(DC); Battery: Inner lithium battery: 11.1 V, 5.2 AH , Up to 180 times splice and heat
- Monitor: Dual cameras cameras, 90︒bi-dirctional
- Fiber Image Magnification: X or Y Separately 360 times or Simultaneously 300 times
- Estimated Splice Loss: Available
- Cleaving angle detection: Available
- Automatic setting: camera, Forward motor
- Tension Test: 1.96~2.25N
- Storage of Splice Result: 6,000 groups of latest splice results
- Splicing Model: Auto & Manual & Full Auto & Stepping
- Optical Fiber Fixture: 3-in -1 cutting fixture; Multipurpose 1+N fixture (for SC/LC/FC connector)
- Terminal: USB for Memorizing and Updating
- Weight: 1.29kg (without battery pack)

NOTE.
-Packing tidak termasuk bubble wrap
-Harap membeli bubble wrap bila mau dibubble wrap
- Resiko kerusakan karena ekspedisi selalu ada dan bukan tanggung jawab seller. Tidak ada garansi perjalanan.
- Pengiriman harian dari Senin s/d Sabtu mulai pukul 14.00 WIB - Hari Minggu dan hari dimana ekspedisi tidak beroperasi tidak ada pengiriman. Hari minggu tetap bisa order namun order akan diproses hari berikutnya.

Kami tidak terima komplain patah, bocor, penyok atau pretelan saat pengiriman karena kita kirim sesuai yang anda pesan.

Happy Shopping:)

Gambar produk
