Detail Freescan Trak Pro CMM 3D Scanner Industrial Grade Precision Portable

3D Zaiku Indonesia



Freescan Trak Pro CMM 3D Scanner Industrial Grade Precision Portable



SKU : Freescan-TRAKPRO
Garansi 1 tahun untuk semua merek Shining 3D yang dijual 3D Zaiku
Tersedia scanner backup penggantian jika mesin sedang reparasi



Kenapa beli 3D Scanner Shining 3D di 3D Zaiku :
1. Garansi FULL mesin 1 tahun, ganti scanner baru dalam 1 bulan pembelian jika terdapat kerusakan
2. FREE Full training pemakaian mesin di toko kita yang khusus 3D Scanner
3. FREE Konsultasi kebutuhan mesin dan upgrade mesin, ada mesin demo ditoko, tersedia juga demo onsite
4. Pembelian khusus di kami tersedia scanner backup penggantian jika mesin sedang reparasi jadi projek tetap berjalan



Accuracy Up to 0.03mm
Volumetric Accuracy 15m³ ,0.1mm
Resolution 0.05mm
Measurement Rate 480,000 measurements/s
Part Size Range (recommended) 0.2–6m
Connection Type Support wireless and wired connection
FreeTrak-Weight 7.2kg
FreeTrak-Dimensions 1079mm x 237mm x 110mm
FreeTrak-Light Source Infrared LED
FreeTrak-Laser Class N/A
FreeTrak-Stand-off Distance 3000mm
FreeTrak-Depth-of-field 2000mm
FreeTrak-Scanning Area 3000mm x 2500mm
Connection Standard IEEE802.11n/ac, IEEE802.3ab
Output Formats ​.stl、​.asc
Operating Temperature Range 5–40°C
Operating Humidity Range (non-condensing) 10–90%
FreeScan Trak-Weight 1.2kg(scanner)+900g(airmaster)
FreeScan Trak-Dimension 210mm*210mm*215mm
FreeScan Trak-Light Souce RED LED & 7 Laser Crosses + 1 extra line
FreeScan Trak-Laser Class Class Ⅱ(eye safe)
FreeScan Trak-Stand-off Distance 300mm
FreeScan Trak-Depth-of-field 250mm
FreeScan Trak-Scanning Area 275mm*250mm



Kelebihan :
- Sangat cocok untuk inspection di industri dan pabrik
- Tidak perlu pasang marker, menghemat tenaga dan waktu
- Scan sangat presisi sampai detail 0,02 mm
- Bisa scan semua jenis permukaan
- Portable dan wireless



Barang Ready Stok,
Hubungi Kita untuk promo harga special tahun ini


Ada FREE Demo unit ditoko kami
Garansi 1 Tahun

Harga 1.188.000.000
