Fan Case Noctua NF-A12x25 PWM 12CM 2000RPM

Detail Fan Case Noctua NF-A12x25 PWM 12CM 2000RPM

Fan Case Noctua NF-A12x25 PWM 12CM 2000RPM
General
Notes and warnings NF-A12x25 further reading:
button Performance comparison to NF-F12 and NF-S12A
button Technical backgrounds and manufacturing challenges
button Interview with Lars Strömbäck (Noctua CTO)
button Which 120mm fan is right for me?
FAN Specification
Size 120x120x25 mm
Mounting hole spacing 105x105 mm
Connector 4-pin PWM
Bearing SSO2
Blade Geometry A-Series with Flow Acceleration Channels
Frame Technology AAO (Advanced Acoustic Optimisation)
Material Sterrox® LCP
Rotational Speed (+/- 10%) 2000 RPM
Rotational Speed with L.N.A. (+/- 10%) 1700 RPM
Min. Rotational Speed (PWM, +/-20%) 450 RPM
Airflow 102,1 m³/h
Airflow with L.N.A. 84,5 m³/h
Acoustical Noise 22,6 dB(A)
Acoustical Noise with L.N.A. 18,8 dB(A)
Static Pressure 2,34 mm H₂O
Static Pressure with L.N.A. 1,65 mm H₂O
Max. Input Power 1,68 W
Max. Input Current 0,14 A
Voltage 12 V
Voltage PWM signal 5 V
MTTF > 150.000 h
Scope of delivery
Low-Noise Adaptor (L.N.A.)
4-pin y-cable
30cm extension cable
NA-AV2 anti-vibration mounts
Anti-vibration gasket for water cooling radiators
Fan screws
