Enermax Aquafusion 120 Square ARGB AIO Water Cooler ELC-AQF120-SQA

Detail Enermax Aquafusion 120 Square ARGB AIO Water Cooler ELC-AQF120-SQA

Enermax Aquafusion 120 Square ARGB AIO Water Cooler ELC-AQF120-SQA
Product Information
AIO CPU Cooler
‧ Glossy acrylic and Aurabelt™ water block for
vivid lighting effects
‧ Patented Dual Chamber water block design
‧ Patented Shunt Channel Technology
‧ ENERMAX SquA RGB fans included
‧ Supports addressable RGB M/B sync
AQUAFUSION, an addressable RGB liquid cooler for Intel® and AMD® CPU platforms, includes a unique RGB water-block with glossy acrylic cover and luminous Aurabelt™ for splendid step-shaped lighting effects. Together with ENERMAX SquA RGB fans, AQUAFUSION can create dynamic visual experience via motherboard software or included control box. The included ENERMAX SquA RGB fans featuring vortex frame design can generate centered and stronger air pressure, especially perfect for radiator. The Patented Dual Chamber design inside water block has a Central Coolant Inlet (CCI) structure, combined with the Shunt-Channel Technology (SCT) on the cold plate, it is able to inject the coolant at the hottest spot to prevent heat surges and shorten the coolant flow path, resulting in faster heat transfer. AQUAFUSION is one of a kind cooling solution for custom gaming rigs or stunning system builds.

Specification


AQUAFUSION 120
Model ELC-AQF120-SQA
CPU Socket Intel® LGA 2066/2011-3/2011/1366/1156/1155/1151/1150
AMD® AM4/AM3+/AM3/AM2+/AM2/FM2+/FM2/FM1
Material Copper Base with Aluminum Radiator
Pump Bearing Ceramic Bearing
MTBF 50,000 hrs
Rated Voltage (V) 12 V
Reted Current (A) 0.7 A
Water Block Rated Current-RGB LED (A) 0.42A (5V)
Fan Dimension 120 x 120 x 26 mm
MTTF ≧ 100,000 hr
Speed 500-2000 rpm
Rated Voltage 12V
Rated Current-Fan (A) 0.38A (12V)
Rated Current-RGB LED (A) 0.68A (5V)
Air Flow 39~79.8CFM
Static Pressure 0.67~3.6mm-H2O
Noise Level 17~32.6dBA
Connector 4 Pin PWM + 4 Pin RGB (W/ extension adapter)
Thermal Grease Dow Corning® TC-5121C

Gambar produk
