Endgame Gear XM1R Mouse Gaming Lightweight

Detail Endgame Gear XM1R Mouse Gaming Lightweight

The XM1r is a refresh of the XM1 Gaming Mouse. Available in an additional two editions, it has an updated PixArt PAW3370 optical sensor and custom-sorted Kailh GM 8.0 switches. It also sports a hybrid skate design and all new firmware and software developed in Germany.

Sensor: PixArt PAW3370
Resolution: up to 19000 CPI (steps of 50 CPI for 50 to 10000 CPI, steps of 100 CPI from 10000 to 19000 CPI; pre-defined: 400, 800 (default), 1600, 3200)
Acceleration: 50g
Max Speed: 400 IPS
Lift-Off Distance (LOD) : 1mm (2mm via software)
Microcontroller: STM32 Arm® Cortex® MCU
Polling Rate: 125, 500 and 1000 Hz (1000Hz by default)
Ergonomics / Layout: dextral
Supported Grip Types: Claw Grip, Palm Grip, Finger Grip
Dimensions: approx. 122.14 x 65.81 x 38.26 mm (L x W x H)
Primary Buttons (right/left): Kailh GM 8.0 switches (Click Force: 55-60gf)
Lifetime: 80 million actuations
Click Detection: Analog Technology (<1ms)
Number of Buttons: 6 (2x top, 2x side, 1x mouse wheel, 1x CPI on bottom)
Wheel Encoder: ALPS (Japan)
Mouse Wheel Scrolling: 2-way
Middle Mouse Button: Kailh tactile switch (Click Force: 70+-10gf)
Micro Side Switches: TTC micro switches
Materials: Plastic (Chassis), PTFE (Glides), Dry Grip Coating (Surface)
Skates: Hybrid Skate Design (small skates pre-installed, large skates included)
Weight: ~70g
Connection Type: wired (USB 2.0 Type A)
Cable: Black Flex Cord 2.0
Color: Black, White, Dark Reflex, Dark Frost

• Lightweight construction - total weight ~70g
• PixArt PAW3370 with up to 19000 CPI
• Pre-sorted Kailh GM 8.0 switches

The XM1r can go beyond traditional signal debouncing to detect clicks thanks to a patented analog technology. This is a superior method compared to normal digital approaches. Whereas digital signal processing can only detect two levels of feedback (1/0), the XM1r implements an advanced algorithm to drive faster click detection for a reaction time of less than 1ms.
