Electric Wire Rope Hoist 5 Ton Samsung Hoist SN05-H6-MH

Detail Electric Wire Rope Hoist 5 Ton Samsung Hoist SN05-H6-MH

Buka setiap hari termasuk hari minggu/libur, silahkan di pesan barang nya dan kami akan mengirimkan barang pesanan anda secepat mungkin.

SAMSUNG HEAVY DUTY Wire Rope Hoist, Made In Korea
• Type : SN05-H6-MH (Single Girder)
• Capacity : 5 Ton
• Lifting Height : 6 mtr
• Hoisting Speed : 4.7 m/min
• Hoist Motor : 5.5 Kw x 6 P
• Traversing Speed : 20 m/min
• Traversing Motor : 0.75 Kw x 4 P x 1
• Control : 48 VAC (Safe for Human)
• Power : 3Ph/380VAC, 50 Hz
• Wire Rope Construction : 6 x (fi)37
• Wire Rope Diameter : Ø16 mm
• Wire Rope Reeving : 2/1
• Width of I-Beam : 125 - 175mm
• Min. Curve Radius : 2300mm
• Overload protector : Digital Adjustable OLP with Buzzer
• ISO Duty Class : M5

Features :
+ Electrification by LS (LG Industrial Systems, Korea)
+ DC Magnetic Disc with auto adjusting mechanism system
+ High resistance Die Cast Motor combine
+ A low starting current with a high starting torque
+ 2 step hoist limiting switch
+ Anti-Sag 200% Braking Capability
+ Control Box with Adjustable Overload Prevention
+ System Simplified Hoist gear system
+ Protective construction for drip proof
+ Drip proof push button switch
+ ED 40% Duty Cycle with 400 no. of starting/hour
+ Warranty : Mechanical 3 years + Electrical 1 year
